AmScope 50X-2000X Darkfield Polarizing Metallurgical Microscope + 3MP Camera
AmScope 50X-2000X Darkfield Polarizing Metallurgical Microscope + 3MP Camera
|
SKU: ME520TB-3M3
Couldn't load pickup availability
Description
The ME520T is a highly versatile microscope for materials inspection using transmitted and reflected light. Primarily designed as an upright metallurgical microscope, the high-power 100W epi-illumination system can be used for brightfield, darkfield, and basic polarized-light. Wafer inspection and metallographic applications will greatly benefit from the illumination modes. The addition of transmitted lighting provides even more flexibility for biological specimens, or backlighting hollow or porous materials. This instrument will be indispensable in any biology, medical, or materials lab.
Monitor and capture photos and videos with the included 3.0MP USB3.0 camera. The C-mount camera is specially designed for use with microscopes, allowing you to watch live images, and to record photos or videos on your computer. This ability to view microscopic images on your computer reduces eye-strain, and allows groups of people to view images at the same time. The USB 3.0 connection provides greater bandwidth for faster frame-rates. A 0.37X reduction lens is included for use with 23mm-30.5mm ports to capture more of the microscope's field-of-view. Our professional software for Windows provides a wide assortment of capture and photo-editing functions including color correction, time-lapse capture, image stitching, and a full complement of measuring tools. A lite version of our software is available for Mac and Linux with essential functionality for capturing photos and videos.
Specifications
| Optical System | Infinite-conjugate | ||||||
| Reference Focal Length | 200mm | ||||||
| Head | Trinocular, 30° incline, 360° rotatable | ||||||
| Interpupillary Adjustment | Siedentopf compensation-free gemel, 48-75mm | ||||||
| Ocular Diameter | 30mm | ||||||
| Ocular Diopters | left ocular | ||||||
| Eyepieces | 10X eyepiece with reticle 10X, 20X |
||||||
| Photo Port | height-adjustable YX series, 23mm tube mount | ||||||
| Objective Lenses | Infinity-corrected | ||||||
| Objective Parfocal Distance | 45mm | ||||||
| Objective Mounting Thread | 3 x RMS 20.32mm, 2 x M25 | ||||||
| Objective Turret | Reverse quintuple, ball-bearing movement | ||||||
| Focusing System | Coaxial coarse and fine focus, tension control | ||||||
| Focus Range |
|
||||||
| Stage Design | Three-layer mechanical stage with caliper | ||||||
| Stage Dimensions | 186mm x 138mm | ||||||
| X-Y Translation Range | 74mm x 50mm | ||||||
| Transmitted Illumination | 100W halogen, continuous-adjustment, rear-mount housing with aspherical collector | ||||||
| Episcopic Illumination | 100W halogen, continuous-adjustment, rear-mount housing with aspherical collector | ||||||
| Condenser | NA0.9/0.25 achromatic swing condenser with iris diaphragm | ||||||
| Sub-stage Condenser-holder | rack and pinion | ||||||
| Power | 100-240VAC 50/60Hz wide-band | ||||||
Objective Lenses
This microscope includes seven objective lenses for metallurgical and biological applications. Two lenses are designated as BD, which can be used for reflected-light darkfield.
Brightfield Metallurgical Objective Lenses |
|||||
| Magnification | Corrections | NA | Working Distance | Cover-glass Thickness | Mount |
|---|---|---|---|---|---|
| 5X | Plan-achromatic | 0.12 | 15.5mm | — | RMS |
| 50X | Plan-achromatic | 0.75 | 0.32mm | 0 | RMS |
| 100X | Plan-achromatic | 0.80 | 2mm | 0 | RMS |
Brightfield/Darkfield Metallurgical Objective Lenses |
|||||
| Magnification | Corrections | NA | Working Distance | Cover-glass Thickness | Mount |
| 10X | Plan-achromatic | 0.25 | 10mm | 0 | M25 |
| 20X | Plan-achromatic | 0.40 | 4.3mm | 0 | M25 |
Transmitted-light Objective Lenses |
|||||
| Magnification | Corrections | NA | Working Distance | Cover-glass Thickness | Mount |
| 40X | Plan-achromatic | 0.65 | 0.54mm | 0.17mm | RMS |
| 100X | Plan-achromatic | 1.25 | 0.13mm | 0.17mm | RMS |
| Camera Specifications | |
| Sensor Type | CMOS |
| Sensor Optical Format | 1/3" |
| Active Pixels | 3M (2048 x 1534) |
| Pixel Size | 2.2µm x 2.2µm |
| Active Sensor Area | 4.51mm x 3.37mm |
| Shutter | electronic rolling shutter |
| Sensitivity | 1.9V/Lux-sec |
| Spectral Response | 380-650nm with IR-cut filter |
| Capture Resolution and Maximum Framerate | 28fps @ 2048x1534 53fps @ 1024x770 |
| Connectivity | USB 3.0 |
| Lens-mount | C-mount |
| Compensating Lens | 0.37X |
| Power | 5VDC over USB |
Software
| OS Requirements | Windows (32/64 bit) XP/Vista/7/8/10, Mac OS 10.8+, Linux kernel 3.13+ | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hardware Requirements | Intel Core2 2.8GHz or comparable processor, 4GB RAM | ||||||||||||||||||
| Features |
|
Packing List:
- One trinocular microscope head
- One microscope body
- One episcopic illuminator
- Two light housings
- Three brightfield metallurgical objective lenses: 5X, 50X, 100X
- Two brightfield/darkfield metallurgical objective lenses: 10X, 20X
- Two brightfield transmitted-light objective lenses: 40X, 100X
- One pair 10X eyepieces
- One pair 20X eyepieces
- One set polarizer and analyzer
- Two lamp bulbs
- Two spare fuses
- One dust cover
- One sample immersion oil
- One C-mount USB camera
- One 0.37X reduction lens
- Two sizing adapters
- One USB 3.0 Type B to type A cable
- One software CD
